WOODWARD 5466-346 Governor Product Details:
Woodward 5466-346 is a digital electronic speed controller commonly used to control the speed of rotating mechanical equipment, such as generators, turbines, engines, etc. These speed controllers are widely used in the industrial sector, especially in the fields of electricity, oil and gas, manufacturing, and aviation, to ensure the reliability and performance of equipment.
Here are some basic information about the Woodward 5466-346 governor:
Speed regulation function: The main function of the 5466-346 speed regulator is to monitor and adjust the speed of rotating mechanical equipment to ensure stable operation within the required working range. This helps to improve the efficiency and reliability of the equipment.
Digital electronic control: This type of governor adopts digital electronic control technology, which has precise control performance and can monitor and adjust the speed in real time.
Programmability: The 5466-346 governor typically has a certain degree of programmability, allowing engineers to configure and adjust according to specific application requirements. This allows them to adapt to various application needs.
Communication interface: Some speed controllers have communication interfaces for data exchange and remote monitoring with other control systems and monitoring equipment.
Reliability and Durability: As these governors are typically used for critical applications, they require high reliability, durability, and anti-interference ability to ensure long-term stable operation of the equipment.
Application areas: Woodward 9907-164 speed controllers are widely used in power plants, oil and gas industries, aviation engines, manufacturing, and other fields. They are used to ensure frequency stability of the generator, constant speed of the turbine, and optimization of engine performance.
Safety: Some speed governors have built-in safety functions that can monitor the operation of equipment and take safety measures when necessary to prevent potential malfunctions or damage.

Product Description
Product number 9907-014 is part of the Woodward 2301A series load sharing and speed control. The 9907-014 model operates within the low-voltage range, with a working power supply of 20-40 Vdc. This model is specifically designed for speed control systems, rather than load distribution and speed control systems.
When using control devices and magnetic pickup sensors, you need to measure the voltage by measuring the 28th and 29th terminals. When the control device is at the starting speed, the minimum voltage on the terminal will be 1.0 V. At the rated speed, Vrms should be 30 V. If for any reason the voltage exceeds 30 V, it is necessary to increase the gap of the speed sensor. When performing these operations, ensure that the voltage at the starting speed is still 1.0 V.
All cables used to connect the control device to the engine must be shielded and must be twisted pair. Never attempt to weld woven shielding. Doing so may result in serious injury and cable failure. When connecting the control device, it must be properly grounded, and the connection from the ground to the grounding plate will provide true grounding for the chassis of the control device.

——————————————————–
