UNS3670A – Z Analog Hybrid Module

UNS3670A – Z Analog Hybrid Module

UNS3670A – Z is a product of ABB, and its detailed information is as follows:
Product type: Analog hybrid module, suitable for automation PLC/DCS equipment.
Model specifications: The common model is UNS3670A – Z V2 HIEE205011R0002.
performance parameter
Channel configuration: 4 inputs, 2 outputs.
Input/output range: The input/output range includes 0V to+10V- 10V to+10V, 0-20mA, 4-20mA, and other options are available to adapt to different types of analog signals.
Resolution: There are two options for input resolution: 16 bit and 12 bit. The output resolution is 16 bit, which can achieve high-precision signal conversion and processing. For example, at a 16 bit resolution, the accuracy in the range of 0V to 10V can reach 0.3125mV/bit.
Accuracy: When the current input is 0 to 20mA, the accuracy is ± 0.25% of the full range at 25 ° C, and ± 0.5% of the full range within the specified operating temperature range; The current output is ± 0.1% of full scale at 25 ° C, with a typical value of ± 0.25%, and ± 0.5% of full scale within the operating temperature range; The voltage output is ± 0.25% of full scale at 25 ° C, with a typical value of ± 0.5%, and ± 1.0% of full scale within the operating temperature range.

Update rate: The update rate of all channels is 2ms, which can quickly respond to signal changes and meet the high real-time requirements of application scenarios.
Product Features
Rich in functions: It has advanced diagnostic functions, including alarm, open circuit, rate of change, over range and under range, etc., which can timely detect and handle abnormal situations in the system. It also has analog output clamp limitations and output ramp mode options, making it easy to flexibly control the output signal.
High stability: able to operate stably in harsh industrial environments, with strong anti-interference ability, providing guarantee for the reliable operation of the system.
High precision: High precision signal conversion and processing capabilities ensure the accuracy of measurement and control, helping to improve the quality and efficiency of the production process.
Application areas: Widely used in power systems, industrial automation, communication equipment, control systems, and renewable energy fields, such as voltage monitoring and conversion for power systems, signal acquisition and control for industrial automation production lines, power conversion and stability for communication equipment, etc
