TVOC-2-240 Arc Monitor ABB
The TVOC-2 arc protection system is an arc protection relay that can alleviate arc faults and help protect personnel and equipment. The arc monitor is the host of the arc protection system, which detects the light of the arc and sends an electrical signal to nearby circuit breakers within 1 millisecond through fast IGBT contacts, thereby disconnecting the power supply and extinguishing the arc. The arc monitor has 10 detector inputs and can trip up to three area selective circuit breakers if needed. Up to 2 expansion units can expand the number of photodetectors to 30, including an HMI that can be placed outside the door. The length range of the detector is wide to accommodate complete switchgear designs. The power supply voltage is 100… 250 V DC or 100… 240 V AC 50/60 Hz. The attachments include current sensing units, optical cables, cable tapes, etc.
The TVOC-2 arc monitoring system adopts the famous TVOC design, focusing more on product reliability, flexibility, and simplicity. This system can provide reliable arc fault solutions for various devices, eliminate potential hazards, and protect personnel and equipment safety. Typical applications include all low-voltage switchgear and medium voltage switchgear.
System Overview: When an arc fault occurs, the response time (measured in milliseconds) is crucial and urgent. The TVOC-2 arc monitoring system can quickly detect arc faults and trip the incoming switch. It takes light as the main criterion for judgment and can cross all other protections and delays, acting instantly.
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
The company has a leading advantage in discontinuing control system components. We have a large inventory and surplus of control system components, as well as some hardware for the discontinued control system. We have also released many new hardware and products to support your existing control system or apply new control technologies. The discontinued “DCS system spare parts, PLC module spare parts,” complete machine and accessories series have a strong advantage. As long as you need PLC products, we can help you find them. The company has a great price advantage.
