Schneider Electric 140 DDO 35300 Overview Modicon Quantum 140 DDO 35300 source OUT module is manufactured by Schneider Electric and used for Quantum EcoStruxure control expert platform. 140 DDO 35300 is a DC output of 24 Vdc and can output 8 groups of 4 points. Features Schneider Electric 140 DDO 35300 is used to convert 24V DC power load. 140 DDO5300 DC output 24 VDC 4 x 8 source module is used with what? It is used to connect to the shared output of 0 V. The modular device has 32 outputs, i.e. eight (8) sets of four (4) output points. When the logic level is true high, the external power supply range of the module is 19.2. 30V DC. The power distribution of the 140 DDO 35300 is 1.75 W+0.4 V x total module load current. The bus current required by Modicon 140DDO 35300 is 330 mA. It uses output blown fuse fault detection and magnetic field power loss. The maximum working voltage of Schneider Electric 140 DDO 35300 is 19.2.0 VDC, while the maximum absolute voltage of 1 ms attenuation pulse is 56 VDC. The voltage drop in the open state is 0.4 VDC @ 0.5 A. The maximum load current of 4 points of Modicon 140 DDO 35300 is 0.5 A, and the maximum load current of 8 groups is 4 A. The maximum load current of the module is 16 A. The maximum surge current at each point of the 140 DDO 35300 output module is 5 mA @ 500 ms duration (no more than 6 per minute). It has a 0.4 mA off state leakage point at 30 VDC. Advantages Schneider Electric 140 DDO 35300 has 1 minute inter-group isolation at 500 VAC RMS, At 1780 VAC RMS “There is 1 minute inter-group isolation under. This Modicon quantum unit has internal transient voltage suppression output protection. Modicon Quantum 140 DDO 35300 has LED indicators to indicate important functions on the output module. When bus communication exists, some of these LED descriptions include green activation. If an error outside the module is detected, a red F error LED will appear. For each of the 32 outputs, when the channel or point is open, – The green indicator LED will be established.

CPU module
CPU module is mainly composed of microprocessor (CPU chip) and memory. In the PLC control system, the factory CPU module is equivalent to the human brain. It continuously collects input signals, executes user programs, and refreshes the output of the system; Memory is used to store programs and data.
2. I/O module
Input module and output module are referred to as I/O module. They are the eyes, ears, hands and feet of the system and the bridge between external field devices and CPU modules.

————————————————————————————–
