MOTOROLA MVME5100 Ethernet controller board

MOTOROLA MVME5100 Ethernet controller board

The Emerson/Motorola MVME-5100 single board computer is a high-performance VME module that adopts the Motorola PowerPlus Il architecture. It can choose from Motorola MPC7400 or MPC7410 processors using AltiVec technology, or low-power MPC750 or MPC755 processors. The MVME5100 integrates a highly optimized PCl interface and memory controller, enabling up to 582MB of memory read bandwidth and 640MB of burst write bandwidth.
Description: The Emerson/Motorola MVME162 is a dual height VME module equipped with MC68LC040 or optional MC68040 microprocessor. The MC68040 microprocessor has — floating-point coprocessing
Equipment; MC68LC040 is not the case MVME1 62 has 1MB, 4MB, or 8MB parity protection DRAM512KB SRAM (with backup battery); One TOD clock (with backup battery); A band
Optional LAN Ethernet transceiver interface for DMA, two serial ports (EIA-232-D and EIA-232-D/EIA-530); Six tick timers with watchdog timer; optional SCSI total with DMA
Line interface; VMEbus interface (local bus to VMEbus/VMEbus to local bus, with A16/A24/A32, D8/D16/D32 bus width and one VMEbus system controller).

The Emerson/Motorola MVME6100 VME single board computer is the first VMEbus single board computer (SBC) designed with Tundra Tsi148 VMEbus interface chip, providing 2eSST VMEbus performance. The 2eSST (Two Edge Source Synchronous Transmission) protocol enables VMEbus to operate at an actual bandwidth of 320MB/s in most cases. The 2eSST protocol has been in existence for some time (the draft trial standard was released in 1999 and became an ANSI standard in 2003), but until now, the 2eSST board will not be able to work on the standard VMEbus backplane because existing VMEbus transceivers cannot support the required VMEbus 2eSST signaling speed. Texas Instruments has developed a new VMEbus transceiver that supports the VMEbus signal exchange speed required by the 2eSST protocol. The combination of the new Texas Instruments VMEbus transceiver and the traditional protocol support of Tsi148 VMEbus allows users to integrate the MVME6100 series into existing infrastructure, providing backward compatibility.

MVME55006E-0163 is the latest product in the Motorola VME series, which can achieve higher levels of performance in a single VMEbus slot. It adopts the latest MPC7455 processor and runs at a frequency of 1 GHz or above, making it very suitable for data-intensive applications. Single board computers have the following characteristics and specifications: MPC7457 PowerPC ® Processor with a clock speed of 1 GHz, 256KB on chip L2 cache and 2MB L3 cache. AltiVec coprocessor with 512MB on board 133 MHz SDRAM ECC memory and 512MB additional memory is used for high-performance computing applications, achieving a total of 1GB of memory through a memory middle layer card. Suitable for IBM compatible host PC software itself, using PLC Chip164 on MS-Windows 9x/ME/NT4.0 complies with IEC61131-3. It is a micro PLC network programming that can be encapsulated in DIP40. It is graphical on KOP/FUB and textual on AWL or ST, following OpenPCS. The integration of CANopen functions in an IEC1131 programming system is a condition for use as an intelligent and decentralized control node. Single board computers can be used in many application fields, such as medical, military, aerospace, and transportation. It can be used as a programming device for IBM compatible host types. The software itself is used on MS-Windows 9x/ME/NT4.0. PLC Chip164 follows the IEC61131-3 standard and can be programmed for graphic processing on KOP/FUB and text processing on AWL or ST. In addition, it also integrates the CANopen function, which can serve as a condition for intelligent decentralized control nodes. [1] The single board computer adopts MPC7457 PowerPC ® Processor with a clock speed of 1 GHz. This processor is a high-performance processor with various functions such as floating-point operations, vector processing, caching, etc. In addition, the processor also features an AltiVec coprocessor, which can be used for high-performance computing applications. [3] MVME55006E-0163 is a single board computer suitable for industrial automation, military, medical, aerospace, and transportation. It has the characteristics of high performance, high reliability, and wide applicability.

Main products:
Automation spare parts such as PLC, DCS, CPU module, communication module, input/output module, power module, PXI module, servo drive, servo motor, controller, encoder, regulator, sensor, fiber interface board, acquisition card, etc

———————————————————-
Disclaimer
Our company sells new products and discontinued products, and purchases these unique products through independent channels. Guizhou Yuanmiao Automation Equipment Co., Ltd. is not an authorized distributor, distributor, or representative of the featured products on this website. All product names/product images, trademarks, brands, and micro logos used on this website are the property of their respective owners. Product descriptions, descriptions, or sales with these name images, trademarks, brands, and logos are for identification purposes only and do not imply any association or authorization with any rights holders.
