FOXBORO FCP280 Process Automation System
FOXBORO FCP280 explain
The on-site control processor 280 is a distributed, optional fault-tolerant on-site installation controller that can execute process control and alarm functions according to user-defined control strategies.
FCP280 requires Foxboro Evo Control Core Services v9.0 or higher version. The system with FCP280 and the software is called Foxboro Evo Process Automation System.
function
Perform regulation, logic, timing, and sequence control together with the connected fieldbus module (FBM)
Perform data collection, alarm detection, and notification
Supports up to 128 compact or standard 200 series FBMs, or up to 128 combinations of 100 series FBMs and 200 series FBMs (with no more than 64 100 series FBMs in this configuration) without the need for a fieldbus communication module.
Expand fieldbus support without the need for fieldbus expansion modules.
Support self hosting mode, even without a host workstation, FCP280 can automatically start by effectively controlling the database.
By utilizing two control modules, unique patented fault-tolerant operations are provided, greatly improving reliability compared to other process controllers
Provide online image upgrade (OLUG) function, which can upgrade fault-tolerant FCP280 without shutting down the process
LCD displays letter errors and real-time roles and statuses
Connect to the mesh control network via standard fiber optic or copper 100 Mbps Ethernet cable
Adopting a sturdy and durable die cast aluminum shell, it can be installed in non ventilated on-site cabinets
Can work in G3 level harsh environments
CE certified, can be installed on-site in cabinets
Each fieldbus port on the FCP280 motherboard is specifically designed to support 2 Mbps or 268 Kbps HDLC fieldbus
Using multifunctional control algorithms and various FBMs to provide control capabilities for various process applications
Support time synchronization using optional external time from GPS satellites
Using a soft keyboard, configuration can be done through the keys on the FCP280 panel.
FCP280 performs regulation, logic, timing, and sequence control together with the connected Foxboro DCS fieldbus module (FBM).
It can also perform data collection, alarm detection, and notification. FCP280 uses a network adapter installed on the motherboard,
Connect to the Foxboro DCS control network using standard fiber optic or 100 Mbps copper cable (see figure below).
FCP280 requires Foxboro DCS control core service software v9.0 or higher.
The system equipped with FCP280 and the software is called EcoStruxure Foxboro DCS process automation system.
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
The company has a leading advantage in discontinuing control system components. We have a large inventory and surplus of control system components, as well as some hardware for the discontinued control system. We have also released many new hardware and products to support your existing control system or apply new control technologies. The discontinued “DCS system spare parts, PLC module spare parts,” complete machine and accessories series have a strong advantage. As long as you need PLC products, we can help you find them. The company has a great price advantage.
Warranty： 365 days
Quality: Original module
Condition： New / Used
Warehouse: Spot
Delivery time: Shipped in 3 days after payment
Mailbox：2645963284@qq.com
Related products：
| FOXBORO | FCP280 |
| FOXBORO | P0917YZ FCP270 |
| Foxboro | FCP280 RH924YA |
| FOXBORO | P0922AG |
| FOXBORO | FBMSVH |
| FOXBORO | 873EC-JIPFGZ-5 |
| FOXBORO | FBM233 |
| FOXBORO | FBM07B |
| FOXBORO | FBM232 P0926GW |
| FOXBORO | FBM227 |
