FOXBORO FBM05 Controller
Product type: Field control processor 270 (FCP270)
Memory size: 16 MB SDRAM 32 MB flash memory
Input voltage (redundant voltage): 24 V DC typical value
Support up to 128 200 series fbms with fieldbus expansion module 100 (FEM100)
Support up to 64 100-series fbms
Fieldbus communication module is not required
Connect to the grid control network through standard optical fiber 100 Mbps Ethernet
Use robust die-cast aluminum housing
Can work in G3 harsh environment
Whether the enclosure field installation has passed CE certification
FBI200 or FBI100 supports 2 Mbps or 268 Kbps HDLC fieldbus at the same time, allowing connection to 200 series and 100 series FBMs (affecting the total number of each FBM supported).
Power consumption (per non-fault-tolerant module): max. 8.5 W
Operating temperature: 0 to+60 ° C (+32 to+140 ° F)
Configuration: single processor module. The fault-tolerant type consists of two processor modules, and an interconnect fault-tolerant connector is integrated on the base plate.
Perform regulation, logic, timing and sequence control with the connected fieldbus module (fbm)
Perform data collection, alarm detection, and notification
Support up to 32 200 series fbms
Two control modules are used to provide unique patented fault-tolerant operation, which greatly improves the reliability compared with other process controllers
Use various control algorithms and various fbms to provide control capabilities for various process applications
Foxboro provides factory automation systems, flow meters, single loop controllers, and various product support services. The company also provides level, pressure, and temperature instruments, as well as nuclear magnetic resonance (NMR) based process analyzers, for use in refineries, petrochemicals, food processing, and pulp and paper operations.
Foxboro Corporation was established in Foxboro, Massachusetts in 1908 and was acquired by Siebe PLC in Windsor, UK in 1990. In 1999, Siebe merged with BTR to establish Invensys plc. Foxboro is a brand under Invensys Systems, Inc. Foxboro/Inventys was acquired by Schneider Electric in 2014.
Foxboro is an extensive instrument supplier with a long-term reputation. In addition to its instrument product series, the company is also known for its I/A series, which was launched in 1987 as a Distributed Control System (DCS).
FBM10 DM400YL (P0400YL) 120VAC AC state input/contact output (2A) 8DI/8DO
FBM11 CM400YM (P0400YM) 240VAC AC state input/contact output (1A) 8DI/8DO
FBM12 CM400YN (P0400YN) contact/DC voltage input extension 16DI
FBM13 DM400YP (P0400YP) 120VAC AC state input extension 16DI
FBM14 CM400YQ (P0400YQ) contact/DC voltage input/contact output extension 8DI/8DO
FBM15 DM400YR (P0400YR) 120VAC AC state input/contact output extension (2A) 8DI/8DO
FBM16 CM400YS (P0400YS) 240VAC AC state input/contact output extension (1A) 8DI/8DO
FBM17 DM400YT (P0400YT) 0-10V DC voltage/contact input/output 4AI/2AO/4DI/4DO
FBM18 P0400YV transmitter input 8AI
FBM20 CM700QV (P0700QV) 240VAC AC state input 16DI
FBM21 CM700TW (P0700TW) 240VAC AC state input extension 16DI
FBM22 P0900HS manual and automatic operation station interface 1AI/1AO
FBM24 DM900HT (P0900HT) point/125V DC voltage input 16DI
FBM25 DM900NX (P0900NX) point/125V DC voltage input extension 16DI
FBM26 DM900HU (P0900HU) contact/125V DC voltage input/output 8DI/8DO
FBM27 DM900NY (P0900NY) contact/125V DC voltage input/output extension 8DI/8DO
FBM39 P0902UT intelligent transmitter input/0-20MA output 4AI/4AO
FBM41 P0902XA contact input/contact output (2.25A) 8DI/8DO
FBM42 P0902XB contact input/contact output (2.25A) extension 8DI/8DO
FBM46 P0950DA redundant intelligent transmitter input/0-20MA output 4AI/4AO
FBM201 P0914SQ DIN installation 0-20MA input 8AI
FBM202
