FOXBORO AD207AV Controller/Driver Board


Product type: Field control processor 270 (FCP270)
Memory size: 16 MB SDRAM 32 MB flash memory
Input voltage (redundant voltage): 24 V DC typical value
Support up to 128 200 series fbms with fieldbus expansion module 100 (FEM100)
Support up to 64 100-series fbms
Fieldbus communication module is not required
Connect to the grid control network through standard optical fiber 100 Mbps Ethernet
Use robust die-cast aluminum housing
Can work in G3 harsh environment
Whether the enclosure field installation has passed CE certification
FBI200 or FBI100 supports 2 Mbps or 268 Kbps HDLC fieldbus at the same time, allowing connection to 200 series and 100 series FBMs (affecting the total number of each FBM supported).
Power consumption (per non-fault-tolerant module): max. 8.5 W
Operating temperature: 0 to+60 ° C (+32 to+140 ° F)
Configuration: single processor module. The fault-tolerant type consists of two processor modules, and an interconnect fault-tolerant connector is integrated on the base plate.
Perform regulation, logic, timing and sequence control with the connected fieldbus module (fbm)
Perform data collection, alarm detection, and notification
Support up to 32 200 series fbms
Two control modules are used to provide unique patented fault-tolerant operation, which greatly improves the reliability compared with other process controllers
Use various control algorithms and various fbms to provide control capabilities for various process applications

Mainly engaged in the advantageous supply of PLC and DCS system spare parts modules of world-famous brands
★ Invensys Foxboro I/A Series system: FBM (field input/output module) sequential control, ladder logic control, accident recall processing, digital-analog conversion, input/output signal processing, data communication and processing, etc.
★ Invensys Triconex: redundant fault-tolerant control system, the most modern fault-tolerant controller based on triple module redundancy (TMR) structure.
★ Westinghouse Westinghouse: spare parts for OVATION system, WDPF system and WEStation system.
★ Rockwell Allen Bradley Rockwell: 1756/1771/1785/1747/1786/1771/2711, Reliance Ryan and other products.
★ Motorola: MVME 162, MVME 167, MVME1772, MVME177 and other series.
★ XYCOM: I/O VME board and processor.
★ SchneiderModicon: Quantum 140 processor, control card, power module, etc.
★ Fanuc: modules, cards, drives and other spare parts.
★ ABB: Bailey INFI 90, industrial robot spare parts DSQC series, etc.
★ Yaskawa Yaskawa: servo controller, servo motor, servo driver.
★ Dr. Bosch Rexroth: Indramat, I/O module, PLC controller, drive module, etc.
★ Woodward: SPC valve position controller, PEAK150 digital controller.FBM01 P0400DA 0-20MA input 8AI
FBM02 P0400YC thermocouple/millivolt input 8AI
FBM03 P0400YD thermal resistance input (three-wire/four-wire system) 8AI
FBM04 P0400YE 0-20MA input/output 4AI/4AO
FBM05 P0400YF redundant 0-20MA input/output 4AI/4AO
FBM06 P0400YG frequency input/0-20MA output 4PI/4AO
FBM07 P0400YH contact/DC voltage input 16DI
FBM08 DM400YJ (P0400YJ) 120VAC AC status input 16DI
FBM09 CM400YK (P0400YK) contact/DC voltage input/contact output 8DI/8DO
FBM10 DM400YL (P0400YL) 120VAC AC state input/contact output (2A) 8DI/8DO
FBM11 CM400YM (P0400YM) 240VAC AC status input/contact output (1A) 8DI/8DO
FBM12 CM400YN (P0400YN) contact/DC voltage input extension 16DI
FBM13 DM400YP (P0400YP) 120VAC AC state input extension 16DI
FBM14 CM400YQ (P0400YQ) contact/DC voltage input/contact output extension 8DI/8DO
FBM15 DM400YR (P0400YR) 120VAC AC state input/contact output extension (2A) 8DI/8DO
FBM16 CM400YS (P0400YS) 240VAC AC state input/contact output extension (1A) 8DI/8DO
FBM17 DM400YT (P0400YT) 0-10V DC voltage/contact input/output 4AI/2AO/4DI/4DO
FBM18 P0400YV transmitter input 8AI
FBM20 CM700QV (P0700QV) 240VAC AC status input 16DI
FBM21 CM700TW (P0700TW) 240VAC AC state input extension 16DI
FBM22 P0900HS manual and automatic operation station interface 1AI/1AO
FBM24 DM900HT (P0900HT) point/125V DC voltage input 16DI
FBM25 DM900NX (P0900NX) point/125V DC voltage input extension 16DI

The I/A Series control system is the first open DCS control system launched by Foxboro in the world in 1987. With the development of the times, I/A Series is also developing, and the controller has also developed to 80 series. The I/A Series control system itself is a very large and complex system. It is necessary to gradually understand the operation of the whole system and system in order to provide effective maintenance means.
Foxboro provides factory automation systems, flow meters, single-loop controllers and various product support services. The company also provides level, pressure and temperature instruments as well as nuclear magnetic resonance (NMR) based process analyzers for refinery, petrochemical, food processing and pulp and paper operations.
Foxboro was founded in Foxboro, Massachusetts, in 1908 and was acquired by Siebe plc in Windsor, UK, in 1990. In 1999, Siebe and BTR merged to establish Invensys plc. Foxboro is a brand of Invensys Systems, Inc. Foxboro/Innvensys was acquired by Schneider Electric in 2014.
Foxboro is an extensive instrument supplier with a long reputation. In addition to its instrument product series, the company is also famous for its I/A series, which is the distributed control system (DCS) launched in 1987. Foxboro has a proprietary protocol called FoxCom, although many of its instrument products now use HART protocol.
