EMERSON A6210 shaft vibration monitoring card
A6210 Emerson Thrust Position, Differential Expansion, and Rod Position Monitor
The A6210 monitor operates in three different modes: thrust position, differential expansion, or rod position.
The thrust position mode accurately monitors the thrust position and provides reliable mechanical protection by comparing the measured axial position with the alarm set point (drive alarm and relay output).
Axial thrust monitoring is one of the most important detection methods for turbomachinery. Sudden and small axial movements should be detected within 40 milliseconds or less to minimize or avoid contact between the rotor and the housing. Suggest using redundant sensors and voting logic. It is strongly recommended to supplement thrust position monitoring with temperature measurement of thrust bearings.
Axial thrust monitoring consists of one to three displacement sensors installed at the shaft end or thrust ring, parallel to the shaft. A displacement sensor is a non-contact sensor that measures the position of an axis.
For extremely critical safety applications, the A6250 monitor provides triple element residual thrust protection based on the SIL3 level overspeed system platform.
Dual channel, 3U size, single slot plug-in module reduces cabinet space requirements by half compared to traditional four channel, 6U size cards
Hot swappable modules that comply with API670 and API618 standards
● Front and rear buffering and proportional output, 0/420mA output, 0-10V output
Self checking facilities include monitoring hardware, power input hardware temperature, simplification, and cables
Built in software linearization facilitates sensor adjustment after installation
● Used together with displacement sensors 642264236424 and 6425 and driver CONXXX
characteristic:
A6110 Dual channel tile vibration measurement module, monitoring bearing vibration.
Can be replaced during operation, can be used independently, with redundant power input.
Extended self checking function, built-in sensor self checking function, password protected operation level.
Suitable for eddy current sensors PR9266… and PR9268… or piezoelectric sensors.
RS232/485 ports are used for on-site configuration and communication, and can read measurement values.
Built in linearization processor,.
Record and store the measurement data of the most recent start/stop.
Emerson A6110 AMS6500 Axis Relative Vibration Monitor
Product Overview
The shaft relative vibration monitor is designed to provide extremely high reliability for the most critical rotating machinery in factories. This 1-slot monitor can be used together with other AMS 6500 monitors to form a complete API 670 mechanical protection monitor.
The main function of the shaft relative vibration monitoring module is to accurately monitor the shaft relative vibration and reliably protect the machinery by comparing vibration parameters and alarm setpoints. Compare vibration parameters with alarm setpoints to drive alarms and relays, thereby reliably protecting machinery.
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
Product series：
PLC and DCS system spare modules from world-renowned brands
Allen Bradley (AB) series products from the United States
Schneider series products
General Electric Series Products
Westinghouse Series Products
Selling ABB Robots FANUC Robots、YASKAWA Robots、KUKA Robots、Mitsubishi Robots、OTC Robots、Panasonic Robots、MOTOMAN Robots。
Estinghouse: OVATION system, WDPF system, MAX1000 system spare parts.
Invensys Foxboro: I/A Series system, FBM (Field Input/Output Module) sequential control, ladder logic control, accident recall processing, digital to analog conversion, input/output signal processing, data communication and processing, etc. Invensys Triconex: Redundant fault-tolerant control system, the most modern fault-tolerant controller based on Triple Modular Redundancy (TMR) structure.
Motorola: MVME 162, MVME 167, MVME1772, MVME177 and other series.
Foxboro: I/A Series system, FBM full series (on-site input/output modules)
Sequential control, trapezoidal logic control, accident recall processing, digital to analog conversion, input/output signal processing
Data communication and processing, etc.
Westinghouse: 1C31 series DCS system, CPU, OVATION system, WDPF system
WEStation system spare parts.
Triconex: Redundant fault-tolerant control system, modern fault-tolerant controller based on Triple Modular Redundancy (TMR) structure.
Emerson: various spare parts such as modules, cards, drives, etc.
ABB: PM full range DCS system, IGCT high-voltage inverter series, industrial robot spare parts DSQC series, INFI 90, etc.
Bailey: BRC series DCS system, etc.
Allen Bradley: 1756, 1785, 1771, 1746 full series systems, etc.
Yokogawa: CP series, etc.
Honeywell: TK/TC/CC systems, etc.
Reliance: 57C series, etc.
Schneider: 140 series processors, control cards, power modules, etc.
Modicon: Spare parts for AS series PLC systems.
Siemens MOORE, Siemens Simatic C1, Siemens CNC system, etc.
Motorola: MVME 162, MVME 167, MVME1772, MVME177 and other series.
XYCOM: I/O, VME board, and processor, etc.
GE (General Electric): IC698/IC697 full range of PLC systems, modules, cards, drivers, and other spare parts.
Yaskawa: Servo controller, servo motor, servo drive.
Bosch Rexroth: Indramat, I/O modules, PLC controllers, drive modules, etc.
Woodward: SPC valve position controller, PEAK150 digital controller
XYCOM: I/O, VME board, and processor, et
Related products：
| EMERSON | 1C31223G01 |
