BENTLY 3500/60 Temperature monitor

BENTLY 3500/60 Temperature monitor

Function: Bently Nevada mechanical condition monitoring
Detailed reference description
Six channel 3500/60 (without recorder) processes signals from RTD (resistance temperature detector) and TC (thermocouple).
The 3500/60 is capable of monitoring temperature or temperature difference, typically used for radial or thrust bearing metal temperatures in accordance with API670, but can also be used for critical process temperatures, such as compressor suction and exhaust temperatures, steam temperatures, motor stator temperatures, etc.
The 3500/60 adjusts the input and compares the adjusted signal with user programmable setpoints that can drive alarms and relay logic in the 3500 relay module. External terminal and internal barrier versions are also available.
The 3500/60 and 3500/61 provide the same functionality, with the 3500/61 providing an additional 4-20mA recorder output for each of its six channels.
The 3500/60 and 61 modules provide six channel temperature monitoring and accept two types of resistors
Temperature detector (RTD) and thermocouple (TC) temperature inputs.
The module adjusts these inputs and compares them with user programmable alarm setpoints.
3500/60 and 3500/61 provide the same functionality except that 3500/61 is for each and 3500/60 does not.
The user programs the module to perform RTD or TC temperature measurement configuration software using a 3500 rack.
Different I/O module RTD/TC non isolated or TC isolated versions are provided.
Users can configure RTD/TC non isolated versions to accept any TC or a mixture of TC and RTD inputs.
The TC isolation version provides 250Vdc channel to channel isolation to prevent external interference.
For the third mock examination redundancy (TMR) configuration, temperature monitors must be installed adjacent to each other in groups of three. When used in this configuration, the system uses two types of voting to ensure accurate operation and avoid single points of failure.

System components
For these modules. The remaining 14 slots in the rack can accommodate any combination of monitors, displays, relays, displays, displays, speakers, speakers, microphones, speakers, and/or speakers, as well as keyphasor modules and communication gateway modules.
All modules are inserted into the rack backplane, consisting of a main module and a related I/O module. The I/O module is installed at the rear of the rack for panel mounted systems, and above the main module for partition mounted systems.
The standard rack depth is 349mm (13.75 inches), while the partition mounting rack depth is 267mm (10.5 inches). NEMA4 and 4X weather proof housing are available when environmental protection or purified air is required.
