BENTLY 125768-01 Interface I/O module

BENTLY 125768-01 Interface I/O module

BENTLY 125768-01 is a continuous online transformer monitoring device used to measure various parameters of insulation oil in power transformers. Here are some detailed information about BENTLY 125768-01:
Function: BENTLY 125768-01 continuously monitors critical fault gases, moisture, and temperature in transformer insulation oil. It can detect faults early and take corrective measures before the problem becomes severe.
Main features: BENTLY 125768-01 adopts a microprocessor based design, allowing for flexible and customizable alarm settings. It has a backlit LCD display screen that displays real-time data, as well as a built-in event log that records alarm and fault events. This device is usually installed in a weather proof enclosure and can be connected to a remote control panel or monitoring system.
Sensor: BENTLY 125768-01 uses proprietary gas and humidity sensors to detect the presence of critical fault gases, such as hydrogen and carbon monoxide, as well as moisture content in transformer oil. It also has a temperature sensor to monitor the oil temperature.
Communication: BENTLY 125768-01 supports various communication protocols, including Modbus, DNP3, and IEC 61850, enabling integration into existing control and monitoring systems.
Power requirements: The device can be powered by AC or DC power, with low power consumption and less than 10 watts.
Application: BENTLY 125768-01 is used for various applications, including power generation, transmission, and distribution, as well as large-scale industrial facilities using power transformers.
Overall, BENTLY 125768-01 is a powerful and reliable transformer monitoring device that provides continuous monitoring and early detection of transformer faults. Its advanced sensors, flexible alarm and communication functions make it an important component of many power system monitoring and control systems.

135137-01 is a position/O module with internal terminals, used for proximitors, RPTs, or DC LVDTs. It was designed and developed by Bentley Nevada. It is part of the 3500/45 monitoring system. The position monitor is a 4-channel device that can receive inputs from rotary potentiometers, proximity sensors, DC linear variable differential transformers, AC linear variable differential transformers, and rotary position sensors (RPTs).
The main function of the position monitor is to provide the following functions:
● By continuously comparing monitoring parameters and predefined alarm settings, alarms are triggered to protect the machine.
● Important machine knowledge for operation and maintenance personnel
The 3500/15 AC and DC power supplies accept a wide range of input voltages and convert them into voltages acceptable to other 3500 modules. The following power supplies are available for the 3500 series machine protection system: – General AC
Power supply – High voltage DC power supply – Low voltage DC power supply
