BENTLY 10244-27-50-01 Controller

BENTLY 10244-27-50-01 Controller

135137-01 is a position/O module with internal terminals, used for proximitors, RPTs, or DC LVDTs. It was designed and developed by Bentley Nevada. It is part of the 3500/45 monitoring system. The position monitor is a 4-channel device that can receive inputs from rotary potentiometers, proximity sensors, DC linear variable differential transformers, AC linear variable differential transformers, and rotary position sensors (RPTs).
The main function of the position monitor is to provide the following functions:
● By continuously comparing monitoring parameters and predefined alarm settings, alarms are triggered to protect the machine.
● Important machine knowledge for operation and maintenance personnel
The 3500/15 AC and DC power supplies accept a wide range of input voltages and convert them into voltages acceptable to other 3500 modules. The following power supplies are available for the 3500 series machine protection system: – General AC
Power supply – High voltage DC power supply – Low voltage DC power supply

The Bently Nevada 3500/15 power supply is a half height module that must be installed in the designated slot on the left side of the rack. A 3500 rack can contain one or two AC and DC power supplies in any combination. any
The power supply can supply power to the entire rack. When two power supplies are installed in one rack, one in the lower slot serves as the main power supply and the other in the upper slot serves as the backup power supply. If installed,
The second power supply is a backup of the main power supply. As long as a second power supply is installed, removing or inserting any power module will not interrupt the operation of the rack. The 3500/15 power supply accepts a wide range of input voltages,
And convert it to a voltage acceptable to other 3500 modules

The 3500/42M Proximitor/Seismic Monitor is a 4-channel monitor that accepts inputs from proximity and seismic sensors, conditional signals provide various vibration and position measurements, and compares conditional signals with user programmable alarms
The 3500/22M Transient Data Interface (TDI) is an interface between the 3500 Monitoring System and Bently Nevada System 1TM mechanical management software. TDI separates the functions of the 3500/20 Rack Interface Module (RIM) and communication processor, such as TDXnet
The Bentley 3500 system is a TSI system, also known as the steam turbine safety monitoring system, mainly used to monitor the main parameters of the steam turbine, such as vibration, displacement, speed, pressure, keyphase, differential expansion, etc
The Bently Nevada 3500 series online monitoring and protection system provides continuous online status monitoring and protection for your unit equipment. The Bently 3500 system and Bently vibration sensors work well together and can accept Bently proximity eddy current sensors, velocity acceleration sensors (such as 330400 and 330500), and various composite sensors (3500/32 small cards)
