BENTLY 3500/33-01-00 RELAY MODULE
The 3500/33-01-00 relay module is a full height 16 channel module that can provide output from 16 relays. Any number of 16 channel relay modules can be placed in any slot on the right side of the frame interface module. Each output of the 16 channel relay module can be independently programmed to execute the required voting logic.
The upgraded front panel and I/O wiring rear panel of Bentley 3500/33 relay module are:
149986-01 Backup 16 Channel Relay Control Module
149992-01 Backup 16 Channel Relay Output Module
3500/32-01-00
3500/32-01-CN
3500/33-01-00
3500/33-01-CN
3500/32-01-00 (149986-02125720-01)
Bentley 3500/32 is a relay module produced by Bentley Nevada (now part of Emerson) for vibration monitoring and health monitoring of mechanical equipment. This module is commonly used in industrial environments, especially in the energy industry (such as electricity, oil and gas) and manufacturing, to monitor the vibration levels and status of rotating machinery equipment (such as turbines, generators, pumps, etc.).
Here are some basic information about the Bentley 3500/32 relay module:
Vibration monitoring: The main function of the 3500/32 relay module is to monitor the vibration level of mechanical equipment. By installing vibration sensors (usually acceleration sensors or speed sensors) onto the device, the module can measure vibration and provide information about the device’s operating condition.
Health monitoring: This module can be used to monitor the health status of mechanical equipment. By analyzing vibration data, abnormal vibration patterns in equipment can be detected, thereby predicting potential faults or damages.
Alarm and protection: The 3500/32 module has alarm and protection functions. When the vibration level exceeds the predetermined threshold or the equipment experiences abnormal vibration modes, the module can trigger an alarm, allowing operation and maintenance personnel to take appropriate measures to prevent equipment failure.
Communication Interface: This module typically has a communication interface that allows vibration data to be transmitted to the monitoring system or data acquisition system for further analysis and recording.
Installation and Configuration: Installing and configuring the 3500/32 module typically requires precise installation and calibration to ensure accurate vibration data collection and analysis.
Application field: This type of relay module is commonly used in industrial fields such as power plants, refineries, chemical plants, manufacturing factories, etc., to monitor the health status of rotating equipment, improve equipment availability and reliability.
