5SHY3545L0010 is a high-performance thyristor module produced by ABB, specifically an integrated gate commutated thyristor (IGCT) module. The following is its detailed information:
product overview
manufacturer: ABB。
Product type: Integrated gate commutation thyristor module.
Product number: 5SHY3545L0010, related numbers include 3BHB013088R0001, 3BHE009681R0101, etc.
Technical Parameter
Nominal voltage: 4500V.
Nominal current: 3500A.
Peak conduction gate current: 1000A.
Peak turn off gate current: 1000A.
Conduction time: 1.5 μ s.
Turn off time: 1.5 μ s.
On state voltage drop: 2.5V.
Off state leakage current: 10mA.
Junction temperature: 125 ° C.
Functional Features
High voltage and high current processing capability: capable of withstanding high voltage of 4500V and high current of 3500A, suitable for high-voltage and high-power power control applications.
Fast switching characteristics: It has fast conduction and turn off capabilities, with conduction and turn off times of 1.5 μ s each, enabling efficient energy conversion and control.
Low switching loss: helps improve system efficiency, reduce energy loss, and minimize equipment heating.
Integrated gate driver: It integrates gate driver function, simplifies external circuit design, and improves system reliability and stability.
Complete protection function: Built in overload protection, short circuit protection, over temperature protection and other functions can ensure the safe operation of the module in harsh working environments.
application area
Industrial power regulation: used for power regulation of various industrial equipment, such as motor speed regulation, power control of heating equipment, etc.
Variable frequency drive: As the core power device in the frequency converter, it realizes the frequency conversion and power control of AC power, and is widely used in industrial automation, elevators, fans, water pumps and other fields.
Power electronic equipment: used in power electronic devices such as high-voltage direct current transmission (HVDC) systems, static var compensators (SVC), active filters (APF), etc., to achieve the conversion and control of electrical energy.
