3500/22M Transient Data Interface Module
3500/22M is a transient data interface module developed by Bently Nevada. It serves as an interface for software compatible with the 3500 monitoring system (System 1 status monitoring and diagnostic software, as well as 3500 system configuration software). TDI combines the 3500/20 rack interface module (RIM function) with communication processors such as TDXnet to collect data.
3500/22M features
In the 3500 rack, TDI is located in the slot next to the power supply. In order to continuously collect steady-state and transient dynamic (waveform) data and transmit it to the host software through an Ethernet link, it interacts with M-series monitors (3500/40M, 3500/42M, etc.).
TDI has traditional static data collection capabilities. However, TDI can also use optional channel enable disks to record dynamic, high-resolution transient data.
Function Description
The 3500 rack contains communication processing functions for TDI. Although TDI performs some tasks shared by the entire rack, it is not a critical component of the monitoring system and is not related to the effectiveness of autonomous mechanical protection in monitoring the entire system.
Each 3500 rack requires one TDI or RIM, and it always occupies slot 1. (Near the power source).
The link between the 3500 monitoring system and compatible software is called the 3500/22M Transient Data Interface (TDI) (System 1 status monitoring and diagnostic software and 3500 system configuration software). TDI combines the 3500/20 rack interface module (RIM function) with communication processors such as TDXnet to collect data.
