3300/20 Dual channel axis displacement monitor
BENTLY 3300/20 Dual Thrust Position Monitor
explain
BENTLY 3300/20 DUALTHRUST POSITION MONITOR is a monitoring system developed by Bently Nevada, specifically designed for continuous measurement and monitoring of the axial position of shafts related to machine tool axial clearance.
Main functions and features
Dual channel monitoring: The monitor has two independent channels that can simultaneously monitor two different positions of the same shaft or axis, improving the accuracy and reliability of monitoring.
Thrust bearing fault detection: Early detection of thrust bearing faults is of great significance for ensuring the safe operation of equipment.
High precision measurement: The measurement of thrust position is achieved by measuring the gap voltage with a proximity probe, which has high precision and stability.
False alarm protection: Due to sensor failure (such as exceeding the range gap), it may be mistaken for thrust position movement, resulting in incorrect thrust alarms. Therefore, it is recommended to use two proximity probes for monitoring and configure them as AND voting (i.e. both sensors must reach or exceed the alarm set point simultaneously to activate the alarm relay) to prevent false alarms.
LED indicator light: Each channel is equipped with a green LED indicator light and a red LED indicator light, which are used to display the operating status and alarm status of monitors, sensors, and on-site wiring.
install and configure
Installation probe: It is usually necessary to install an axial probe to directly monitor the thrust ring to ensure the accuracy of the measurement results.
Configuration parameters: Users can configure the parameters of the monitor according to their actual needs, including alarm setpoints, channel selection, etc.
Debugging and Calibration: After installation and configuration, debugging and calibration are required to ensure that the monitor can work properly and accurately reflect the actual status of the equipment.
Application scenarios
BENTLY 3300/20 DUALTHUST POSITION MONITOR is widely used in various industrial fields that require high-precision thrust position monitoring, such as power generation, petrochemicals, steel, etc. Especially suitable for critical equipment that requires extremely high operational and health conditions, such as steam turbines, compressors, etc.
Maintenance and upkeep
Regular inspection: Regularly check the monitor and probe to ensure they are in good working condition.
Cleaning and maintenance: Clean and maintain the monitor and probe to avoid dust and dirt accumulation that may affect measurement accuracy.
Replace damaged parts: If the monitor or probe is found to be damaged or malfunctioning, the damaged parts should be replaced in a timely manner to ensure the normal operation of the equipment.
Attention: Due to the large number of products from our company, the pictures cannot match each other. Please contact me to confirm the actual product!
